Tabla de equivalencias AWG a milímetros

 TPI = turns-per-inch, vueltas por pulgada. Útil para el cálculo de bobinados. Diam(mm) = diámetro en milímetros. Circ-mils = área de la sección recta en mils circulares (1 circ-mil = d^2 siendo d el diámetro en mils). Ohms/kft = resistencia en Ohms por cada 1000 pies (1 pie = 0.3048 metros). Ft/Ohm = Número de pies requeridos para 1 ohm de resistencia. Amps = Tasa de corriente admisible basado en 750 circ-mils por ampere. MaxAmp = Corriente máxima admisible basado en 500 circ-mils por ampere.

AWG	TPI	Diam(mm)	Circ-mils	Ohms/Kft	Ft/Ohm	Amps	MaxAmps
4/0 = 0000	21.740	11.684	211592	0.0490	20402	282.12	423.18
3/0 = 000	24.412	10.405	167800	0.0618	16180	223.73	335.60
2/0 = 00	27.413	92.657	133072	0.0779	12831	177.43	266.14
1/0 = 0	30.783	82.513	105531	0.0983	10175	140.71	211.06
1	34.567	73.480	83690	0.1239	8069.5	111.59	167.38
2	38.817	65.436	66369	0.1563	6399.4	88.492	132.74
3	43.588	58.272	52633	0.1970	5075.0	70.177	105.27
4	48.947	51.893	41740	0.2485	4024.7	55.653	83.480
5	54.964	46.212	33101	0.3133	3191.7	44.135	66.203
6	61.721	41.153	26251	0.3951	2531.1	35.001	52.501
7	69.308	36.648	20818	0.4982	2007.3	27.757	41.635
8	77.828	32.636	16509	0.6282	1591.8	22.012	33.018
9	87.396	29.063	13092	0.7921	1262.4	17.456	26.185
10	98.140	25.881	10383	0.9989	1001.1	13.844	20.765
11	11.020	23.048	8233.9	12.596	793.93	10.978	16.468
12	12.375	20.525	6529.8	15.883	629.61	87.064	13.060
13	13.896	18.278	5178.3	20.028	499.31	69.045	10.357
14	15.605	16.277	4106.6	25.255	395.97	54.755	82.132
15	17.523	14.495	3256.7	31.845	314.02	43.423	65.134
16	19.677	12.908	2582.7	40.156	249.03	34.436	51.654
17	22.096	11.495	2048.2	50.636	197.49	27.309	40.963
18	24.813	10.237	1624.3	63.851	156.62	21.657	32.485
19	27.863	0.9116	1288.1	80.514	124.20	17.175	25.762
20	31.288	0.8118	1021.5	10.153	98.496	13.620	20.430
21	35.134	0.7229	810.10	12.802	78.111	10.801	16.202
22	39.453	0.6438	642.44	16.143	61.945	0.8566	12.849
23	44.304	0.5733	509.48	20.356	49.125	0.6793	10.190
24	49.750	0.5106	404.03	25.669	38.958	0.5387	0.8081
25	55.866	0.4547	320.41	32.368	30.895	0.4272	0.6408
26	62.733	0.4049	254.10	40.815	24.501	0.3388	0.5082
27	70.445	0.3606	201.51	51.467	19.430	0.2687	0.4030
28	79.105	0.3211	159.80	64.898	15.409	0.2131	0.3196
29	88.830	0.2859	126.73	81.835	12.220	0.1690	0.2535
30	99.750	0.2546	100.50	103.19	96.906	0.1340	0.2010
31	112.01	0.2268	79.702	130.12	76.850	0.1063	0.1594
32	125.78	0.2019	63.207	164.08	60.945	0.0843	0.1264
33	141.24	0.1798	50.125	206.90	48.332	0.0668	0.1003
34	158.61	0.1601	39.751	260.90	38.329	0.0530	0.0795
35	178.11	0.1426	31.524	328.99	30.396	0.0420	0.0630
36	200.00	0.1270	25.000	414.85	24.105	0.0333	0.0500
37	224.59	0.1131	19.826	523.11	19.116	0.0264	0.0397
38	252.20	0.1007	15.723	659.63	15.160	0.0210	0.0314
39	283.20	0.0897	12.469	831.78	12.022	0.0166	0.0249
40	318.01	0.0799	98.880	1048.9	0.9534	0.0132	0.0198
